Supporting 802.3, 802.u Faster Ethernet, IEEE 802.3ab 1000BASE-T;
Supports POE IEEE 802.3af/at compliant Powered Device (PD)
Modes: Normal switch mode/Watch dog model(automatically manage
CCTV cameras power supply)/VLAN model
Ports 1~24 gigabit ports features POE power supply capability and
can be used as Power over Ethernet devices;2*1000Base-X SFP.
Support full duplex based on IEEE802.3x and half duplex based on Backpressure
Auto MDI/MDIX crossover for all ports
Support non-blocking wire speed forwarding
MAC address auto-learning & auto-aging
Steel case, the total POE power budget of 320W
Just Plug and Play
Interface : 24*10/100M/1000M POE ports (Data /Power) – 2*1000M uplink SFP slot port (Data)
Dimensions: 440mm*180mm*43mm(L x W x H )
