5 10/100/1000Mbps RJ45 ports, Auto-Negotiation & Auto MDI/MDIX
IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
10Gbps switching fabric capacity/backplane bandwidth
Support 9216-byte jumbo packet length forwarding at wired speed
Supports 2K MAC address table, MAC address auto-learning & auto-aging
Green Ethernet technology for effective power saving
LED indicators for simple diagnostics and management
Plug and play ,no configuration required
| Hardware | |
| Interface | 5* 10/100/1000M TX ports |
| LED | PWR, LAN1-LAN5 |
| Power Supply | DC 9V/500mA (Output) |
| Dimensions (L x W x H ) | 130 x 70 x 26 mm |
| Cabling Type | 10Base-T: UTP Cat.3 or up 100Base-TX: UTP Cat.5 or up 1000Base-TX: UTP Cat.5 or up |
| Software | |
| Standard | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE802.3ab 1000Base-T |
| Access Method | CSMA/CD |
| Transmission Method | Store and Forward |
| Switch Architecture | Non-blocking |
| Data Transmission Rate | 10/100Mbps(Half-duplex) 20/200/2000Mbps(Full-duplex) |
| MAC Address Table | 2K |
| Others | |
| Certification | FCC, CE |
| Environment | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing |
| Package | 1* ST3105GS 1* 9V/500mA Power Adapter 1* Quick Installation Guide |
