Τεχνικά Χαρακτηριστικά
INPUT
Voltage 110/120 VAC or 220/230/240 VAC
Voltage Range 81-145 VAC / 162-290 VAC
Frequency Range 60/50 Hz (Auto sensing)
OUTPUT
Output Voltage 110/120 VAC or 220/230/240 VAC
AC Voltage Regulation (Batt. Mode) ±10%
Frequency Range (Batt. Mode) 60 Hz or 50 Hz ±1 Hz
Transfer Time Typical 2-6 ms, 10ms max
Waveform (Batt. Mode) Simulated Sinewave
BATTERY
Battery Type & Number 12 V/7 Ah x 1
Typical Recharge Time 4-6 hours recover to 90% capacity
PROTECTION
Full Protection Overload, discharge, and overcharge protection
INDICATORS
LCD Display AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, and Low Battery
ALARM
Battery Mode Sounding every 10 seconds
Low Battery Sounding every second
Overload Sounding every 0.5 second
Battery Replacement Alarm Sounding every 2 seconds
Fault Continuously sounding
PHYSICAL
Dimension, D x W x H (mm) 287 x 100 x 142
Net Weight (kgs) 4.25
Optional USB/RS-232 Port Supports Windows® 2000/2003/XP/Vista/2008, Windows2 7/8,10 Linux, and MAC
